General Descriptions:
All-digital beamforming technology;
16 rates scanning depth adjustment;
USB2.0 for real-time picture uploading to PC;
Puncture lead function, angle adjustable;
Scanning angle adjustment;
10 Inch B/W SVGA Monitor;
Two Probe Jacks;
Multi-Freq Autoregulation;
8 segment TGC adjustment;
Probe automatic identify;
Digital encoder knobs;
Gamma corrections, Stat. Histogram;
Automatic report generation(Normal/OB).
| Technical Specification: | |
| Scanning mode: | Convex/Linear/Micro-convex |
| Display modes: | B, B+B, B+M, 4B |
| Scanning depth: | 240mm / 16 level adjustment |
| Gray scales: | 256 |
| Cine-loop: | 819 frames(Max) |
| Image permanent storage: | ≥ 32frames |
| Image conversion: | up/down, left/right, black/white |
| Resolution Lateral: | Side≤ 2mm, Axial≤ 1mm |
| Local zoom: | 2 times both in real-time and frozen |
| Electronic Focus: | 4-Sectors Dynamic |
| Frequency : | 2.5/ 3.5/ 5.0/ 6.5/ 7.5 |
| Measurement: | distance, circumference, area, volume, EF rate, heart rate |
| Obstetric measurments: | BPD, GS, CRL, FL, AD, HC, AC, EDD, GA, Fw etc. |
| Probes selectable: | convex, linear, micro-convex, transvaginal and Rectum |
| Monitor: | 10 inch SVGA |
| Video output: | PAL-D / USB 2.0 |
| Body marks: | no less than 40 marks |
| Notation: | date, time, name, sex, age, doctor, hospital, annotation
(whole screen comment input) |
| Application: | abdominal, OB/GYN, urology, pediatrics, cardiology, small
parts examination, etc. |
| Power supply: | 220V~240V, 50/60Hz |
| Standard configuration: | R60/3.5 MHz Convex (80 Crystal) |
| Optional : | R13/6.5 MHz Transvaginal Concex |
| R20/5.0 MHz Micro-Convex | |
| 7.5MHz Rectum Linear | |
| 7.5MHz Linear | |
| Video Printer | |
| Trolley | |
| Puncture frame | |
| PACKING SPECIFICATION: | |
| Net Weight: | 11.5 KG ( inc. one probe ) |
| Gross Weight: | 13.5 KG |
| Size: | 355mm× 315mm× 255mm |
| Packing Volume: | 425mm× 395mm× 410mm |
