SY-A015 Factory price mini handheld farm vet ultrasound machine
Brand Name: Sunnymed
Model Number: SY-A015
Packaging Details: Carton or wooden case, standard export packing
Delivery Detail: In 10 days after payment received
Port: Guangzhou
MOQ：1 set
Description
Technical specification
| Model | SY-A015 | ||
|
Probes |
3.5MHzMechanical sector | ||
| Displayed Depth (mm) | 120-190 | ||
| Maximal detect depth (mm) | ≥140 | ||
|
Resolution (mm) |
Lateral |
≤3 (depth≤80) |
|
| Axial | ≤1 (depth≤80) | ||
| Blind area (mm) | ≤8 | ||
|
Geometric position Precision (%) |
Horizontal |
≤15 |
|
|
Vertical |
≤10 |
||
| Monitor size (inch) | 5.0 TFT-LCD | ||
| Display modes | B,B+B,B+M,M | ||
| Image gray scale | 256 levels | ||
| Image multiplying factor | ×1.0, ×1.2, ×1.5, ×2.0 | ||
| Measure functions | Distance, circumference, area, heart rate, gestation age | ||
| Character display | Case history no., age, sex | ||
| Battery capacity | 2200mAh | ||
| Mainframe power | 13W at non-charging operation / 25W at charging operation | ||
| Adapter power consumption | 45W
|
||
| Mainframe | 800g | ||
