Clinical Applications:
Dialysis Access
Vascular Access
Pain management
Point-of-Care(POC)
Anesthesia
Line Placement (CVC, PICC)
Primary Care
Emergency & ICU
General Practitioners
Urological
OB/GYN
Abdominal
Specification of Handheld Ultrasound Scanner:
| Product Description | Handheld UltrasoundScanner |
| Monitor | 6 inch LCD high-resolution (1280*720) full touch screen |
| Probe Type | 128 elements |
| Frequency | Convex array 2-5MHZ / Linear array 5-10MHZ |
| Imaging Mode | B ,C ,M, PW, Steer |
| Color Doppler | Gain, Steer, PRF, WF etc. |
| Cine-loop | 1024 Frames |
| Frame Rate | Convex:16fps/Linear:24ps |
| Depth | Convex:≤200mm / Linear: ≤70mm |
| Grayscale | 256 level |
| Gain | Convex: 0~150dB adjustable Linear: 0~120dB adjustable |
| Image Processing | Line smoothing, Frame smoothing, Transversal filter, Longitudinal filter, Sharpening, Gamma transformation, etc. |
| Power | Built-in battery(5400mAh) to support 2h for continuous scanning |
| Image Format | JPEG, DICOM |
| Language | Over 60 different language including English, Spanish, German, Russia, Portuguese, Turkish, Polish, Italian etc. |
| Measurement | Length, Area, Arrow, Angle, Perimeter, Text. |
| Camera | 5M auto focus |
| Wireless Connection | WIFI, BLUETOOTH,3G/4G(LTE,WCDMA/EDGE/GPRS/GSM) |
| Memory | 64GB |
| Connection Interface | Micro USB2.0, HDMI,3.5mm headphone jack, |
| Operating System | Android |
| Printer | WIFI printer |
| File Management | Patient file & image file |
| Cloud | Cloud image storage, cloud file management, standard API & SDK interface, Information sharing platform |
| Technical Training | Online and offline tutorial, self-built online training material |
| Remote SoftwareUpdate | Yes |
| Product Size | 165*85*23mm |
| Net Weight | Convex:570g / Linear:550g |
| Standard Configuration | Main unit (Monitor and 1pc Transducer included): 1set USB wire: 1pc Adapter: 1pc Carrying bag: 1pc |
