Description

Specifications:
·Parameters: RBC, WBC, SQEP (squamous epithelial cells) , NSE (non-squamous epithelial cells),

pathological casts, mucus, crystals, bacteria, yeast, sperm, and others
·Principles of operation: Auto microscopic measurement with flat flow cell
·Counting cell: double channels, thickness of inner chamber: 0.1 mm
·Throughput: 40~60 samples / hour
·Three types test mode: fast, standard, refined
·Test mode: Auto mode, STAT mode
·Bar code: internal auto bar code reader
·Sample: native urine samples or urine sediment samples
·Sample volume: Minimum volume:2.5 ml non-centrifugal urine
Aspiration volume:1ml
·Batch size: 50 samples, 10 samplesx5 racks
·Memory Capacity: more than 50,000 results (include images)
·Interfaces: USB, RS232 serial port, parallel interface, LAN port
·Power supply: AC100~240V, 50/60Hz
·Dimension: 650mm(W) x 670mm(H) x 640 mm(D)

Features:
·Double counting channels in flow cell
·Whole viewfield microscopic images of sediment
·Automatic identification and classification of urine particles
·Walk-away automation, high efficient washing system
·High-efficiency washing system, automatic flow cell and probe washing system
