Description

Features

Random access
Up to 30 samples can be scanned simultaneously
Throughput: up to 60 samples /hour
Temperature compensation refer to 18oC according to Westergren method

ESR curve display and print-out
Touch screen , large LCD display
Built-in internal thermal recorder

Specifications

Area of application                Erythrocyte sedimentation rate analysis
Measuring principle               Infrared sensor
Reading channels                  30 available channels
Loading capability                 Up to 30 samples at a time
Loading pattern                     Random

Measuring time                      30 minutes or 60 minutes selectable
Throughput                            Up to 60 samples per hour
Analysis result                        In Westergren ESR value (mm/hr)
Temperature compensation    Refer to 18°C automatically (selectable)
Reading resolution                 0.2mm
Reproducibility                      < 0.3% or 2mm/1h

Result resolution                   1mm/1h
Blood level range                  50mm~64mm
Display                                 LCD screen with backlight
Input                                    Touch screen
Interface                               RS-232 serial port

Print                                     Internal thermal recorder
Power supply                       AC 220V/110V ±10%, 50/60/Hz, 50W
Operation conditions            Temperature 15C°~32°C Humidity ≤85%
Dimension                            400mm×300mm×200mm(L×W×H)
Net weight                           11.5kg
