Description

Instrument characteristics

1,The first temperature-programmed steps in domestic which can set any functions

greatly expand the range of analysis application.

2,New EPC / AFC gas system, control the pneumatic flexibly.

3,FID wide range design, A→ A extend the line range of sample analysis.

4,The outstanding large volume and high-temperature column oven which can get to 450

high-temperature control technology. Also it can achieve negative temperature operation,

with liquid nitrogen / dry ice get to -80 ° C / -50 ° C.

5,Apply with highly-sensitive micro-thermal conductivity which can greatly improve the analytical sensitivity.

6,A variety of hardware configuration option projects which provide a flexible foundation for

the development of a special analysis system.

7,Support multi-valve and multi-column switching technique which can turn the complex samples into simple analysis.

8,Support GC-MS technology

9,Introduce the foreign advanced PC control workstation software technology, which can support

5Q certificate and comply with the management of GMP / GLP and 21 CFR Part 11 regulations.

Column oven dimension: 278×310×165mm=14.2L

Temp. control range: RT+5℃~450℃(0.1℃increment)

Programming temp.-ramp speed:0-120℃/min

Programming temp.-ramp : any step

Fast cool down: 250~100℃≤1.5minutes
Temp. accuracy: ±0.1℃
