Description

Unique outline design, skillful and portable
Clear and bright color LCD with real time display and large LED display values
Intelligent Measuring of NIBP/SpO2/PR/PLETH/TEMP
Storage/Review trend data up to 129 hours and 3888 groups
Audio and visual alarm
Built-in rechargeable Li-ion battery, up to 4-hour power supply
Automatic shutdown for power saving
Unique Tele-monitoring and Synchronization retransmit function
Utility PC software package for long time real time monitoring, web transferring,

history data uploading/review/print/storage.

Technical Specifications:

1. General Specifications:
Size: 300mm×183mm×99mm
Net Weight: 1110g
Display Specification
Measurement Display: color LCD screen & LED
Power Supply Indicator: Dual-color LED (red/green)
Classification:BF type applied part

2. Power Supply
AC Power Adaptor:
Input: 100~240VAC, 50/60Hz
Output: DC 5V, 2A
Battery:
Li-ion rechargeable battery, 3.7V, 3AHr
Operating Time: 4 hours with full battery capacity.
(Condition: 25℃, NIBP working period is 10 minutes)
Recharge Time: 8 hours

3. Environment
Temperature
Working:0~45C
Transport and Storage: -25~85C
Humidity
Working:15 ~95 %
Transport and Storage: 10 ~95 % (no condensation)

4. Monitoring Parameter
SpO2
Measurement object: Adult, Pediatric, Neonate
SpO2%
Measuring Range:0~100%
Resolution:1 %
Accuracy:2 %(90~99%), 3 %(70~89%),unspecified (0~69%)
Pulse Rate
Measuring and Alarm Range:30~250bpm
Resolution: 1bpm
Accuracy: 1bpm
NIBP
Measurement object: Adult, Pediatric
Method: Oscillometric
Mode: Manual, Auto, STAT
Measuring Interval in AUTO Mode: 1, 2, 3, 5, 10, 15, 20, 30, 45, 60 (min)
Measuring Period in STAT Mode: 5 min
Cuff Pressure Range:0 ~300mmHg
Pulse Rate Range:30~250bpm
Measurement Rage: Adult 30~255mmHg, Pediatric 30~160mmHg
Over-pressure Protection: Adult 300mmHg, Pediatric 220mmHg
Pressure Resolution : 1mmHg
Temperature
Input: Body surface thermal-sensitive resistor temperature sensor
Measuring Range: 0~50℃
Accuracy: 0.1℃

5. Storage and Review
Maximum Data Quantity: 3888 groups
