Features :
Portable and delicate design, very easy and convenient to operate
Accurate pulse pace identification function
High accuracy digital filter, automatic baseline adjustment
Working modes: Manual, Automatic, Arrythmia Analysis, Storage
210mm, 12 channel format recording, excellent automatic interpretation
800×480 graphic 7 inch color LCD to simultaneously display ECG information
Alphanumeric keyboard to operate, very convenient to use
250 patient cases storage ( SD card storage is optional )
Detailed patient information record, available for roll and Z-fold thermal paper
Adapt to 110-230V,50/60Hz power supply. Built-in rechargeable Li-ion battery
USB / Rs232 communication port support USB storage, laser printer printing and PC ECG
software ( Optional )
Technical Specification :
| Lead | Standard 12 leads |
| Lead acquisition | 12bit/1000Hz (synchronously 12 leads) |
| Work mode | Manual / Auto / R-R Analysis |
| Filter | . AC Filter : 50Hz / 60Hz . EMG Filter : 25Hz / 45Hz . Anti-Drift Filter : 0.15Hz ( Adaptive ) |
| CMMR | ≥120dB ( with AC Filter ) |
| Calibrating voltage | 1mV ±2% |
| Power supply | . AC 110-230V ( 10%), 50/60Hz ( 1Hz ), 40VA . DC Rechargeable Li-ion battery,2000mAh or 4400mAh |
